1 Passage Pneumatic + Electrical Rotary Joints

◆ Support M5, G1 / 8, G1 / 4, G3 / 8, G1 / 2, G3 / 4, G1 thread for pneumatic

◆ Dynamic sealing technology

◆ With NSK high precision bearing

◆ Abrasion resistant, low torque, high speed

◆ Can be combined to transfer 2~96 circuits power and signal

Description

Electrical Data Mechanical Data
Rated VoltagePower: 0~240 VAC/VDC
Signal: 0~440 VAC/VDC
Max. Speed400RPM
Insulation ResistancePower: ≥1000MΩ/500VDC
Signal: ≥1000MΩ/500VDC
Max. Pressure10Bar
Insulation Strength500VAC@50Hz, 60sWorking Temperature-30℃~+80℃
Lead WiresStandard (adjustable)Working Humidity0~85% RH
Lead LengthStandard 300mm (adjustable)Housing MaterialAluminum Alloy
Electrical Noise<0.01ΩProtection GradeIP51

ModelAA1A2BCC1DD1EFHLL1L2QCircuitsCurrent
MPHD1M5-S0605M5M5M513M5M54949304040557183665A
MPHD1M5-S01205M5M5M517M5M559593950505571866125A
MPHD1M5-S01802M5M5M517M5M559593950505571866182A
MPHD1M5-S02402M5M5M517M5M559593950505571866242A
MPHD1M5-S03602M5M5M522M5M559593950505571871362A
MPHD1M5-S05605M5M5M522M5M559593950505571891562A
MPHD1M5-S01805M5M5M522M5M559593950505571893185A
MPHD1M5-S02405M5M5M522M5M5595939505055718110245A
MPHD1M5-S03005M5M5M522M5M5595939505055718127305A
MPHD1M5-S03605M5M5M522M5M5595939505055718147365A
MPHD1M5-S04205M5M5M522M5M5595939505055718167425A
MPHD1M5-S04805M5M5M522M5M5595939505055718182485A
MPHD1M5-S06005M5M5M522M5M5595939505055718227485A
MPHD118-S0605G1/8G1/8G1/822M5M55959395050757293665A
MPHD118-S01205G1/8G1/8G1/822M5M559593950507572966125A
MPHD118-S01802G1/8G1/8G1/822M5M559593950507572966182A
MPHD118-S02402G1/8G1/8G1/822M5M559593950507572966242A
MPHD118-S03602G1/8G1/8G1/826M5M564644355557572971362A
MPHD118-S05602G1/8G1/8G1/826M5M564644355557572992562A
MPHD118-S01805G1/8G1/8G1/831M5M569694960607572995185A
MPHD118-S02405G1/8G1/8G1/831M5M5696949606075729112245A
MPHD118-S03005G1/8G1/8G1/831M5M5696949606075729130305A
MPHD118-S03605G1/8G1/8G1/831M5M5696949606075729150365A
MPHD118-S04205G1/8G1/8G1/831M5M5696949606075729168425A
MPHD118-S04805G1/8G1/8G1/831M5M5696949606075729183485A
MPHD118-S06005G1/8G1/8G1/831M5M5696949606075729223605A
MPHD114-S0605G1/4G1/4G1/423M6M66969495959819343665A
MPHD114-S01205G1/4G1/4G1/428M6M674745364648193466125A
MPHD114-S01802G1/4G1/4G1/428M6M674745364648193466182A
MPHD114-S02402G1/4G1/4G1/428M6M674745364648193466242A
MPHD114-S03602G1/4G1/4G1/432M6M674745364648193466362A
MPHD114-S05602G1/4G1/4G1/432M6M674745364648193497562A
MPHD114-S01805G1/4G1/4G1/432M6M674745364648193499185A
MPHD114-S02405G1/4G1/4G1/432M6M6747453646481934117245A
MPHD114-S03005G1/4G1/4G1/432M6M6747453646481934135305A
MPHD114-S03605G1/4G1/4G1/432M6M6747453646481934155365A
MPHD114-S04205G1/4G1/4G1/432M6M6747453646481934175425A
MPHD114-S04805G1/4G1/4G1/432M6M6747453646481934190485A
MPHD114-S06005G1/4G1/4G1/432M6M6747453646481934230605A
MPHD138-S0605G3/8G3/8G3/827M6M68484647474969393565A
MPHD138-S01205G3/8G3/8G3/832M6M689896979799693964125A
MPHD138-S01802G3/8G3/8G3/832M6M689896979799693964182A
MPHD138-S02402G3/8G3/8G3/832M6M689896979799693964242A
MPHD138-S03602G3/8G3/8G3/832M6M689896979799693970362A
MPHD138-S05602G3/8G3/8G3/832M6M689896979799693995562A
MPHD138-S01805G3/8G3/8G3/837M6M6949474848496939100185A
MPHD138-S02405G3/8G3/8G3/837M6M6949474848496939117245A
MPHD138-S03005G3/8G3/8G3/837M6M6949474848496939135305A
MPHD138-S03605G3/8G3/8G3/837M6M6949474848496939158365A
MPHD138-S04205G3/8G3/8G3/837M6M6949474848496939174425A
MPHD138-S04805G3/8G3/8G3/837M6M6949474848496939193485A
MPHD138-S06005G3/8G3/8G3/837M6M6949474848496939233605A
MPHD112-S0605G1/2G1/2G1/231M6M68989687979969393765A
MPHD112-S01205G1/2G1/2G1/237M6M694947384849693966125A
MPHD112-S01802G1/2G1/2G1/237M6M694947384949693966182A
MPHD112-S02402G1/2G1/2G1/237M6M694947384849693966242A
MPHD112-S03602G1/2G1/2G1/237M6M694947384949693966362A
MPHD112-S05602G1/2G1/2G1/237M6M694947384849693966562A
MPHD112-S01805G1/2G1/2G1/242M6M699997889899693999185A
MPHD112-S02405G1/2G1/2G1/242M6M6999978898996939119245A
MPHD112-S03005G1/2G1/2G1/242M6M6999978898996939135305A
MPHD112-S03605G1/2G1/2G1/242M6M6999978898996939155365A
MPHD112-S04205G1/2G1/2G1/242M6M6999978898996939170425A
MPHD112-S03605G1/2G1/2G1/242M6M6999978898996939188485A
MPHD112-S06005G1/2G1/2G1/242M6M6999978898996939209605A

Lead Wires Color Code

Ring# 1 2 3 4 5 6 7 8 9 10 11 12
Color RED YEL BLK BLU GRN WHT PUP GRY BRN ORN DBLU YEL-GRN
12 color wires as one group, if more than 12 wires, repeat as sequence. Can be customized
