Table Application Fields of Slip Ring Products
Application; Defense & Aerospace
Features; FORJ integration, EMC shielding, 1000A+ power channels, Hydraulic and pneumatic integration, Electro-optical systems
Application; Industrial & Commercial
Features; Explosion proof units, High reliability low maintenance, Oil filled units for sub-sea applications
Application; Radar
Features; Integration of high frequency channels, EMI/RMI shielding as standard, Integration with all bus systems, Integration of optical rotary or RF joints, Low maintenance, high reliability units
Application; Test Equipment
Features; Speed in excess of 20,000 rpm, Temperature ranges, Shock and vibration resistance, High humidity levels, Low electrical noise levels, Excellent repeatability
Application; Wind Turbines
Features; Easily integrated with hydraulic systems and fluid rotary joints, Systems can be designed with integrated Fiber Optic Joints(FORJ), 20-25 year lifespan, with 5-year maintenance intervals, Brushes with auto wear detection, auto changeover available, Dual tracks to further extend unit life, Modular design for easy part replacement or upgrade, Typical protection levels of IP65
Application; Video & Optical Systems
Features; Standard units and custom design, Transmission of high definition video with high frame rate, 360-degree continuous panning, Integration of rotary joints and Ethernet, Fully gimbaled systems, Twist capsule integration
Slip Ring for Defense & Aerospace
Missile guidance systems and stabilised navigation platforms
Gimballed avionic instruments and gyroscopes
Missile launchers and weapon pedestals
Fighting vehicles, RBJ units (transferring signals and power from turret to hull)
Airborne stabilized gun platforms and sights
FLIR systems
Submarine ICBM systems
Fixed-wing aircraft and helicopters for propeller and rotor de-icing systems
Slip Ring for Industrial & Commercial
Mechanical handling
Robotics
Lifting equipment and cable reelers
Hazardous area equipment
Satellite assemblies
Wind tunnels
Subsea applications
Remotely operated vehicles
Slip Ring for Radar
Land-based civil radar systems for air traffic control
Marine radar systems for Naval and Merchant vessel navigation
Land-based radar systems for military use such as target acquisition and surveillance
Airborne radar for navigation
Slip Ring for Test Equipment
Gas turbine research
Aircraft type testing
Centrifuge construction
Wind tunnels
Formula 1 engine and brake system testing
Slip Ring for Wind Turbine
Blade pitch control
Heating
Generator excitation
Slip Ring for Video & Optical Systems
Target acquisition systems
Surveillance
Outside broadcast boom-mounted cameras
Studio broadcast TV equipment
CCTV
Gimballed electro-optics
Analog Devices offers a broad range of high performance integrated and discrete RF and microwave components across the entire frequency spectrum that enable application specific designs for a contactless Gbps-level data transmission via rotary joints. This article proposed an integrated and a discrete data interface solution utilizing millimeter wave electromagnetic waves to transfer data between a rotor and a stator. The proposed solution offers not only high speed data transmission, ultralow latency, negligible bit error rate, strong interference attenuation, and maintenance free operation but it can also withstand higher misalignments and permits transmission over larger distances to enable a wi 00006000 de range of slip ring assemblies to meet the ever increasing needs of modern industrial applications.
